QUICK NOTES:
- RMS OUTPUT: 1300W RMS
- COIL SIZE: 2.75 INCH
- CUTOUT: 9.45 inches (240 mm)
- MOUNTING DEPTH: 7.36 inches (187 mm)
- NET WEIGHT: 31.7 lbs (14.4 kg)
- GROSS WEIGHT: 35.3 lbs (16 kg)
- XMAX : 28 mm (one-way)
- MOTOR SIZE: 6.69 in - 170 mm | 3.35 inches (Radius)
Precision Engineering: Engineered with an optimized motor strength (BL Product: 27.077 T·m) and an effective piston area (Sd) of 56.305 cm² for powerful sound output at an affordable price.
Technical Specifications:
- Revc (DC Resistance): 2.960 Ohm
- Resonance Frequency (Fo): 40.881 Hz
- Total Moving Mass (Mms): 322.255 g
- Suspension Compliance (Cms): 46.472 μm/N
- Equivalent Volume (Vas): 8.642 L
- Sensitivity (SPL): 83.0 dB
- Qms (Mechanical Q): 2.303
- Qes (Electrical Q): 0.455
- Qts (Total Q): 0.380
- Voice Coil Inductance (Le): Not specified
- Mechanical Resistance (Rms): 0.782
- Sealed Enclosure: .5 cubic foot
- Ported Enclosure: 1.0 cubic feet
- Outside Diameter: 10.79 in (274mm)
- Displacement: 0.09 cu ft
Why You Should Buy:
- High-Power Performance: This subwoofer delivers 1300W RMS of powerful, punchy bass, making it ideal for high-demand audio systems.
- Versatile Compatibility: The 2-ohm DVC setup allows for multiple wiring configurations, making it perfect for various car audio installations.
- Durable Build: Constructed with premium materials, including a carbon fiber dustcap, to withstand high sound pressure levels and ensure long-lasting performance.
- Premium Carbon Fiber Dustcap: Adds strength, rigidity, and a sleek look, enhancing both performance and aesthetics.
- Perfect for Any Setup: Whether you're upgrading your daily driver or building a show car audio system, the DBz 10" subwoofer offers the perfect blend of affordability and power.
