DC Audio Level 2 Subwoofers

DC Audio Level 2 Subwoofers

Regular price $239.99 USD
Regular price Sale price $239.99 USD
Sale Sold out
Size
Ohms

With more power handling than before, the Level 2 is back and better than ever!

This sub has everything you need in a daily driver except the cost. This is one of our greatest accomplishments.

It starts out with a double stacked FEA optimized motor. A chrome top plate and T yoke to keep it looking good. It has 22 mm of X-Max, progressive spider, 2.5" voice coil, cast basket and push terminals.

This sub works great in sealed or ported enclosures.


    Key Features

    • Extremely rigid non-pressed paper cone assembly
    • Multilayered polymer wide roll foam surround
    • Polypropylene dust cover with DC logo
    • Dual 8" OD flat linear roll spiders
    • Heavy duty interweaved tinsel lead wire sewn to the spider
    • Cast aluminum black frame
    • FEA analyzed and optimized motor assembly - Fully CNC machined
    • Rubber mounting gasket
    • Rubber Motor Boot
    • Chrome spring loaded push terminals
    • 2.5” Hi-temp copper voice coil wound on black anodized voice coil former
    • Rubber magnet cover



    M3 Level 2 Subwoofers 10" 12"
    Mounting Depth 5.5" 6.1"
    Mounting Hole Diameter 9.35" 11.00"
    Outside Driver Diameter 11" 12.5"
    VC Diameter 2.5" 2.5"
    Displacement .12 ft .14ft
    Power Handling rms/peak 600/1200 600/1200
    Ohm Options d2/d4 d2/d4
    Sd 324 cm 481 cm
    Vas 13.89 L 30.6 L
    Cms 0.095 Mm/n 0.095 Mm/n
    Mms 210 g 245 g
    Fs 35.6 Hz 33 Hz
    Bl 24 N/A 24 N/A
    Re 7.2 Ohm 7.2 Ohm
    Le 7 mH 7 mH
    Qms 8.96 8.46
    Qes 0.592 0.639
    Qts 0.555 0.594
    Xmax 22mm 22mm
    Ref SPL @1 watt 82.1 db 84.2 db
    Suggest Sealed Box .5 ft .75 ft
    Suggested Ported Box 1.0 ft 1.25 ft
